Tractor · 2008Unverified

Bobcat CT120

Name: Bobcat CT120
Brand: Bobcat

Bobcat CT120 — Compact Utility tractor · 15 hp. Reference specifications; pending source verification.

The Bobcat CT120 is a compact tractor rated at 15 hp, one of the smaller options in its class. Manufactured from 2008 to 2010, the CT120 features a 3-cylinder diesel liquid-cooled engine driving a four-wheel drive system via a hydrostatic transmission. Weighing 932 kg, it is designed for work on plots of approximately 200 acre.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

15 hp

Max power

21 hp

Weight

932 kg

Catalogue coverage

Variants represented

Richest spec table

88 rows

Recorded power

15 hp

Recorded weight

932 kg

Transmissions

hydrostatic

Production years

2008-2010

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorBobcatReference

ManufacturerDaedongReference

Compact Utility tractorReference

Built in Daegu, South KoreaReference

Four-wheel driveReference

Power steeringReference

Two-post folding ROPS.Reference

Engine

Daedong 0.9L 3-cyl dieselReference

Fuel tank20.1 LReference

Engine15.7 kWReference

Daedong 3C093Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke75 x 70 mmReference

EmissionsTier IIReference

Power15.7 kWReference

Rated RPM2800Reference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,800 rpmReference

Emissions complianceTier IIReference

Bore and stroke2.95x2.76 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeHSTReference

forward and reverse optionsHydrostatic; Infinite F&R (2-range)Reference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)10.8 kWReference

Valves1Reference

Total flow29.1 lpmReference

Rear Type1Reference

Rear lift (at 24"/610mm)435 kgReference

Rear PTOliveReference

Rear PTO Type540Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase147 cmReference

Weight932 kgReference

Front tire23x8.5-12Reference

Rear tire33x12-16.5Reference

Weight110 kgReference

Ag front23x8.5-12Reference

Ag rear33x12-16.5Reference

Ag front6x12Reference

Ag rear9.5x16Reference

Lawn/turf front23x8.5-12Reference

Lawn/turf rear33x12.5-16.5Reference

Length268 cmReference

Width118 cmReference

Height207 cmReference

Ground clearance27 cmReference

Bobcat CT120 attachments

54" mid-mount mower deckReference

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

54" mid-mount mower deckReference

Front-end loaderReference

54" Mower deck

Typemid-mount BobcatReference

Type3-blade with hydraulic liftReference

Cutting width137 cmReference

Speeds

9.5x16 rear tires.Reference

General

Make & ModelDaedongReference

Cruise controlAvailableReference

SCV controlJoystickReference

Rollover protective structureTwo-post folding ROPSReference

Country of manufacturerSouth KoreaReference

Capacities

Capacity56.6 ciReference

Power

Max Power21 hpReference

PTO

PTO Power14.5 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTO RPM2,000 RPMReference

Hydraulics

Pump Rated Output (total)7.7 gpmReference

Remote Valves1 valvesReference

Rear Hitch category (SAE designation)Category 1Reference

Dimensions & weight

Overall Height207.8 cmReference

Overall Length268.5 cmReference

Overall Width118.1 cmReference

Overall weight932.1 kgReference

Wheels & tyres

Rear Wheel TypeAg rear - 33x12-16.5 | 9.5x16 | Lawn/turf rear - 33x12.5-16.5Reference

Operator station

Cab AvailabilityOptionalReference

Seat SuspensionTRUEReference

Steering & brakes

Steering typePowerReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
