Tractor · 2008Unverified
Bobcat CT225
Bobcat CT225 — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1370 kg
Hover a source tag to verify
Overview
DistributorBobcatReference
ManufacturerDaedongReference
Compact Utility tractorReference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
folding ROPSReference
Variants
CK27similar Kioti modelReference
Engine
Daedong 1.3L 3-cyl dieselReference
Fuel tank29.9 LReference
Engine18.6 kWReference
Daedong TD1300LXEReference
dieselReference
3-cylinderReference
liquid-cooledReference
The TD1300LX engine was used in very early models of the CT225. These tractors are based on the Kioti CK25.Reference
Displacement1.3 LReference
Power18.6 kWReference
PTO & Hydraulics
PTO (claimed)14.5 kWReference
Valves1 or 2Reference
Pump flow31.0 lpmReference
Total flow48.1 lpmReference
Steering flow17.0 lpmReference
Rear Type1Reference
Rear lift (at 24"/610mm)555 kgReference
Rear lift (at 24"/610mm)635 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase167 cmReference
Weight1370 kgReference
Front tire25x8.5-14Reference
Rear tire15x19.5Reference
Weight129 kgReference
Weight468 kgReference
Weight474 kgReference
Ag front25x8.5-14Reference
Ag rear15x19.5Reference
Ag front7x14Reference
Ag rear11.2x24Reference
Lawn/turf front25x8.5-16Reference
Lawn/turf rear13.6x16Reference
Length300 cmReference
Width141 cmReference
Height243 cmReference
Ground clearance25 cmReference
Bobcat CT225 attachments
66" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
backhoeReference
Attachment overview
66" mid-mount mower deckReference
SnowblowerReference
Front-end loaderReference
BackhoeReference
66" Mower deck
Typemid-mount BobcatReference
Type3-blade with hydraulic liftReference
Cutting width167 cmReference
Bobcat 6TB Backhoe
Backhoe typeBobcat 6TB BackhoeReference
Digging depth198 cmReference
Reach from pivot271 cmReference
Bucket force1304 kgReference
Dipperstick force791 kgReference
Bobcat 7TB Backhoe
Backhoe typeBobcat 7TB BackhoeReference
Digging depth228 cmReference
Reach from pivot298 cmReference
Bucket force1282 kgReference
Dipperstick force917 kgReference
Transmission
TransmissionhydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Speeds
11.2x24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
