Tractor · 2019Unverified
Bobcat CT4045
Bobcat CT4045 — Compact Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
3373 to 3523 pounds
Hover a source tag to verify
Overview
DistributorBobcatReference
ManufacturerDaedongReference
Compact Utility tractorReference
Original price was $23,884 in 2019Reference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
CT4045ROPSReference
CT4545cabReference
Engine
Daedong 1.8L 3-cyl dieselReference
Fuel tank45.0 LReference
Engine (gross)33.5 kWReference
Daedong 3FTReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke87 x 102 mmReference
EmissionsTier 4Reference
Power (gross)33.5 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
hydrostaticReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Shuttle PTO (claimed)31.0 kWReference
Hydro PTO (claimed)24.5 kWReference
Typeopen centerReference
Pump flow36.4 lpmReference
Total flow54.9 lpmReference
Steering flow18.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)1231 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase180 cmReference
Weight3373 to 3523 poundsReference
Front tire8-16Reference
Rear tire13.6-24Reference
Weight499 kgReference
Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference
Length318 cmReference
Width160 cmReference
Height (ROPS)245 cmReference
Shuttle Operating weight1529 kgReference
Hydro Operating weight1598 kgReference
Ground clearance36 cmReference
Bobcat CT4045 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Bobcat BH86 Backhoe
Backhoe typeBobcat BH86 BackhoeReference
Transport height236 cmReference
2-Foot flat digging depth243 cmReference
Reach from pivot320 cmReference
Loading height203 cmReference
Swing Arc180°Reference
Bucket force1700 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
