Tractor · 2019Unverified

Bobcat CT4045

Name: Bobcat CT4045
Brand: Bobcat

Bobcat CT4045 — Compact Utility tractor · 45 hp. Reference specifications; pending source verification.

The Bobcat CT4045 is a compact tractor with a rated power output of 45 hp, making it suitable for smaller-scale operations. Introduced in 2019, it features a 3-cylinder turbocharged diesel liquid-cooled engine, transmitting power through a four-wheel drive system with hydrostatic transmission. The weight of the CT4045 ranges from 3373 to 3523 pounds. It is designed for use on small to medium-sized properties, typically up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Weight

3373 to 3523 pounds

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

45 hp

Recorded weight

499 kg

Transmissions

8-speed synchronized shuttle

Production years

2019

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorBobcatReference

ManufacturerDaedongReference

Compact Utility tractorReference

Original price was $23,884 in 2019Reference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Variants

CT4045ROPSReference

CT4545cabReference

Engine

Daedong 1.8L 3-cyl dieselReference

Fuel tank45.0 LReference

Engine (gross)33.5 kWReference

Daedong 3FTReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

EmissionsTier 4Reference

Power (gross)33.5 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed synchronized shuttleReference

hydrostaticReference

Typesynchronized shuttleReference

Gears8 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Shuttle PTO (claimed)31.0 kWReference

Hydro PTO (claimed)24.5 kWReference

Typeopen centerReference

Pump flow36.4 lpmReference

Total flow54.9 lpmReference

Steering flow18.7 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)1231 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase180 cmReference

Weight3373 to 3523 poundsReference

Front tire8-16Reference

Rear tire13.6-24Reference

Weight499 kgReference

Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference

Length318 cmReference

Width160 cmReference

Height (ROPS)245 cmReference

Shuttle Operating weight1529 kgReference

Hydro Operating weight1598 kgReference

Ground clearance36 cmReference

Bobcat CT4045 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Bobcat BH86 Backhoe

Backhoe typeBobcat BH86 BackhoeReference

Transport height236 cmReference

2-Foot flat digging depth243 cmReference

Reach from pivot320 cmReference

Loading height203 cmReference

Swing Arc180°Reference

Bucket force1700 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
