Tractor · 2019Unverified

Bobcat CT4055

Name: Bobcat CT4055
Brand: Bobcat

Bobcat CT4055 — Compact Utility tractor · 55 hp. Reference specifications; pending source verification.

The Bobcat CT4055 is a compact tractor rated at 55 hp. Introduced in 2019, this model is powered by a 3-cylinder turbocharged diesel liquid-cooled engine, which drives through a four-wheel drive system with an 8-speed gearbox. The tractor has a weight of 1529 kg and is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Max power

55 hp

Weight

1529 kg

Catalogue coverage

Variants represented

Richest spec table

92 rows

Recorded power

55 hp

Recorded weight

1529 kg

Transmissions

8-speed synchronized shuttle

Production years

2019

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorBobcatReference

ManufacturerDaedongReference

Compact Utility tractorReference

Original price was $26,327 in 2019Reference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Daedong 1.8L 3-cyl dieselReference

Fuel tank45.0 LReference

Engine (gross)41.0 kWReference

Daedong 3FTReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

EmissionsTier 4Reference

Power (gross)41.0 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3Reference

Emissions complianceTier 4Reference

Transmission

8-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears8 forward and reverseReference

Transmission TypeSync ShuttleReference

forward speed rangeOption 1: 17.5 mph\\nOption 2: 17 mphReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)37.0 kWReference

Typeopen centerReference

Pump flow36.4 lpmReference

Total flow54.9 lpmReference

Steering flow18.7 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)1231 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase180 cmReference

Weight1529 kgReference

Front tire8-16Reference

Rear tire13.6-24Reference

Weight499 kgReference

Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference

Length315 cmReference

Width160 cmReference

Height (ROPS)245 cmReference

Operating weight1529 kgReference

Ground clearance36 cmReference

Bobcat CT4055 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Bobcat BH86 Backhoe

Backhoe typeBobcat BH86 BackhoeReference

Transport height236 cmReference

2-Foot flat digging depth243 cmReference

Reach from pivot320 cmReference

Loading height203 cmReference

Swing Arc180°Reference

Bucket force1700 kgReference

General

Make & Model0.9 mReference

Cruise controltrueReference

Capacities

Capacity111 cu in.Reference

Power

Max Power55 hpReference

Rated Power50.3 hpReference

PTO

PTO Power49.6 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 rpmReference

Mid PTOAvailableReference

Mid PTO RPM2,000 rpmReference

Steering & brakes

BrakesWet Multi DiscReference

Steering typePower SteeringReference

Hydraulics

Pump Rated Output (total)53.4 l/minReference

Steering & Implements flow4.5 gpm (9.6 gpm)Reference

Rear Hitch category (SAE designation)Category 1Reference

Rear Hitch maximum lift capacity814.2 kgReference

Dimensions & weight

Overall Height247.4 cmReference

Overall Length318.8 cmReference

Overall Width177.3 cmReference

Turning radius8.7 feet (without Brakes)Reference

Overall weight1,698.7 kgReference

Wheels & tyres

Rear Wheel TypeRear Industrial (AG, Turf)Reference

Front Wheel TypeFront Industrial (AG, Turf)Reference

Operator station

Seat SuspensionAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
