Bobcat CT5545
Bobcat CT5545 — Compact Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
1957 kg
Hover a source tag to verify
Overview
DistributorBobcatReference
ManufacturerDaedongReference
Compact Utility tractorReference
Original price was $35,895 in 2019Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Daedong 1.8L 3-cyl dieselReference
Fuel tank56.0 LReference
Engine (gross)33.5 kWReference
Daedong 3FTReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke87 x 102 mmReference
EmissionsTier 4Reference
Power (gross)33.5 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)25.3 kWReference
Pump flow53.0 lpmReference
Total flow98.4 lpmReference
Steering flow45.4 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)1290 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase190 cmReference
Weight1957 kgReference
Front tire8-16Reference
Rear tire13.6-24Reference
Weight499 kgReference
Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference
Lawn/turf front29-12.5-15Reference
Lawn/turf rear21.5L-16.1Reference
Industrial front10-16.5Reference
Industrial rear14.9-24Reference
Length354 cmReference
Width167 cmReference
Height (cab)242 cmReference
Operating weight1957 kgReference
Ground clearance33 cmReference
Bobcat CT5545 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Bobcat BH86-5 Backhoe
Backhoe typeBobcat BH86-5 BackhoeReference
Transport height236 cmReference
2-Foot flat digging depth243 cmReference
Reach from pivot320 cmReference
Loading height203 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1700 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
