Lawn Tractor · 1995Unverified
Bolens 13069 ST150
Bolens 13069 ST150 — Suburban Late Series · 15 hp. Reference specifications; pending source verification.
The Bolens 13069 ST150 is a lawn tractor model rated at 15 hp, positioning it centrally within its class in terms of power output. Manufactured in 1995, this model features a 1-cylinder petrol air-cooled engine, which drives two-wheel drive through a 6-speed gearbox. Suitable for tasks covering up to 200 acres, this model offers a range of capabilities.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Catalogue coverage
Variants represented
2
Richest spec table
30 rows
Recorded power
15 hp
Transmissions
6-speed gear
Production years
1995-1995
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorBolensReference
ManufacturerNomaReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
15HP Tecumseh 490cc 1-cyl gasolineReference
Tecumseh OHV15Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement29.9 ciReference
Bore/Stroke90 x 76 mmReference
Power11.2 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
TransmissionPeerless 930Reference
Typebelt-driven gearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Bolens 13069 attachments
39" mid-mount mower deckReference
13069 Serial Numbers
Location:Serial number tag on the rear fender, under the tractor seat, on the right side.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
39" Mower deck
Typemid-mount BolensReference
Type2-bladeReference
Cutting width99 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
