Lawn Tractor · 1989Unverified
Bolens 3010G ST100
Bolens 3010G ST100 — Suburban Series · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Hover a source tag to verify
Overview
ManufacturerBolensReference
Lawn tractorReference
Built in Port Washington, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
10HP Briggs & Stratton 361cc 1-cyl gasolineReference
Fuel tank18.9 LReference
Briggs & Stratton 255707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement22.04 ciReference
Bore/Stroke87 x 60 mmReference
Power7.5 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
5-speed gearReference
TransmissionPeerless 920Reference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase114 cmReference
Front tire15x6.00-6Reference
Rear tire20x8.00-10Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x8.00-10Reference
Length175 cmReference
Width87 cmReference
Height107 cmReference
Bolens 3010G attachments
36" mid-mount mower deckReference
42" mid-mount mower deckReference
snowblowerReference
bladeReference
3010G Serial Numbers
Location:Serial number tag on the rear fender, under the tractor seat, on the left side.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH45Reference
Attachment overview
36" mid-mount mower deckReference
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
