Lawn Tractor · 1963Unverified
Bolens 800
Bolens 800 — Tube Frame Series · 7 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
7 hp
Weight
269 kg
Hover a source tag to verify
Overview
ManufacturerBolensReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator stationReference
Engine
7.25HP Wisconsin 304cc 1-cyl gasolineReference
8.25HP Wisconsin 331cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Wisconsin S7DReference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement18.6 ciReference
Bore/Stroke76 x 67 mmReference
Power5.4 kWReference
Air cleaneroil bathReference
Rated RPM3600Reference
Oil capacity0.9 LReference
Wisconsin S8DReference
Displacement20.2 ciReference
Bore/Stroke79 x 67 mmReference
Power6.2 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
3-speed gearReference
TransmissionBolensReference
TypegearReference
Gears3 forward and 1 reverseReference
Oil capacity2.4 LReference
Oil typeEP 90 Gear LubeReference
Dimensions
Wheelbase107 cmReference
Weight269 kgReference
Front tire4.00-8Reference
Rear tire6.00-12Reference
Lawn/turf front4.00-8Reference
Lawn/turf rear6.00-12Reference
Length158 cmReference
Width76 cmReference
Height101 cmReference
Shipping weight269 kgReference
Bolens 800 attachments
32" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
32" mid-mount mower deckReference
SnowblowerReference
BladeReference
32" Mower deck
Typemid-mount BolensReference
Type3-bladeReference
Cutting width81 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
