The Bolens DGT-1700 is a lawn tractor model with a rated power of 17 hp, a mid-range figure for its class. It was manufactured from 1988 to 1991 and features a 3-cylinder diesel liquid-cooled engine, paired with two-wheel drive and a hydrostatic transmission. The model has an operating weight of 465 kg and is suited for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
465 kg
Catalogue coverage
Variants represented
2
Richest spec table
60 rows
Recorded power
17 hp
Recorded weight
465 kg
Transmissions
hydrostatic
Production years
1988-1991
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerBolensReference
Garden tractorReference
The DGT-1700 carried Bolens model code 5117H.Reference
Two-wheel driveReference
Open operator stationReference
Engine
17HP Mitsubishi 696cc 3-cyl dieselReference
Fuel tank15.1 LReference
Mitsubishi L3AReference
dieselReference
3-cylinderReference
liquid-cooled horizontal-shaft inlineReference
Displacement42.48 ciReference
Bore/Stroke65 x 70 mmReference
Power (gross)12.7 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.6 LReference
Oil change100 hReference
Transmission
hydrostaticReference
TransmissionEaton 11Reference
Typeshaft-driven hydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity7.6 LReference
Oil typeMobilfluid 423Reference
Oil change100 hReference
PTO & Hydraulics
Rear Type0Reference
Typesleeve hitchReference
Front PTOindependentReference
Clutchelectro-magneticReference
Front PTO TypeshaftReference
Engine RPM2000@3600Reference
Dimensions
Wheelbase124 cmReference
Weight465 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length194 cmReference
Width97 cmReference
Height121 cmReference
Shipping weight465 kgReference
Ground clearance16 cmReference
Bolens DGT-1700 attachments
42" mid-mount mower deckReference
48" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
48" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
The DGT-1700 was compatible with a 33-inch shaft drive tiller (51333).Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
