Tractor · 1978Unverified
Bolens G152
Bolens G152 — Model year 1978-19811981-1991 · 15 hp. Reference specifications; pending source verification.
The Bolens G152 is a tractor with an approximate engine rating of 15 hp, positioning it at the lower end of its class in terms of power output. It was manufactured from 1978 to 1991. The tractor is equipped with a 2-cylinder diesel liquid-cooled engine and a 4-wheel drive system paired with a 6-speed gearbox. Its listed operating weight is 469 kg, with a maximum suitable working area of 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
469 kg
Catalogue coverage
Variants represented
2
Richest spec table
64 rows
Recorded power
15 hp
Recorded weight
469 kg
Transmissions
6-speed unsynchronized gear
Production years
1978-1991
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorBolensReference
ManufacturerIsekiReference
Sub-Compact Utility tractorReference
Two-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical internal expanding brakesReference
Open operator station.Reference
Variants
G1522WDReference
G1544WDReference
TX1300similar Iseki modelReference
Engine
Mitsubishi 0.7L 2-cyl dieselReference
Fuel tank12.1 LReference
Engine11.2 kWReference
Mitsubishi KE 70Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement0.7 LReference
Bore/Stroke73 x 80 mmReference
Power11.2 kWReference
Air cleanerdry elementReference
Pre-heatingglow plugsReference
StarterelectricReference
Starter volts12Reference
Coolant capacity4.2 LReference
Oil capacity2.6 LReference
Oil change100 hReference
Transmission
6-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity12.3 LReference
Three gears (1-3) plus reverse (R) with additional high-low range shift. Tractor must be stopped, and clutch used, to shift gears and range.Reference
PTO & Hydraulics
Rear PTOtransmissionReference
Rear PTO Type472/752/1177Reference
Engine RPM472@2700Reference
Engine RPM752@2700Reference
Engine RPM1177@2700Reference
Dimensions
Wheelbase128 cmReference
Weight469 kgReference
Front tire4.00-12Reference
Rear tire8-16Reference
Standard tires (ag)Front: 4.00-12. Rear: 8-16Reference
Lawn/turf front20x8.00-10Reference
Lawn/turf rear8-16Reference
Length194 cmReference
Width96 cmReference
Height119 cmReference
Ground clearance27 cmReference
Front tread71/87 cmReference
Rear tread73/83/93 cmReference
Bolens G152 attachments
42" mid-mount mower deckReference
snowblowerReference
bladeReference
G152 Serial Numbers
Location:Serial number plate near gear shift.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH45Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
42" Mower deck
Typemid-mount BolensReference
Cutting width106 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
