Tractor · 1981Unverified
Bolens G292 TS2902
Bolens G292 TS2902 — Compact Utility tractor · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1193 kg
Hover a source tag to verify
Overview
DistributorBolensReference
ManufacturerIsekiReference
Compact Utility tractorReference
Two-wheel driveReference
Differential lockmechanical standardReference
SteeringmanualReference
Mechanical shoe brakesReference
Open operator station. Two-post ROPS (#17370) optional with optional canopy.Reference
Variants
G2922WDReference
G2944WDReference
TS2810similar Iseki modelReference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank30.3 LReference
Engine21.6 kWReference
Iseki 3AA1Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power21.6 kWReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Torque86.1 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Clutchdual-stage dry discReference
PTO & Hydraulics
Typeopen centerReference
Pressure146.9 barReference
Pump flow20.4 lpmReference
Rear Type1Reference
Controlposition and draft controlReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase175 cmReference
Weight1193 kgReference
Front tire5.00-14Reference
Rear tire12.4x24Reference
Standard tires (ag)Front: 5.00-14. Rear: 12.4x24Reference
Length309 cmReference
Width149 cmReference
Height200 cmReference
Ground clearance35 cmReference
Front tread111 to 149 cmReference
Rear tread119 to 152 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
