Lawn Tractor · 1986Unverified
Bolens Villa 936
Bolens Villa 936 — Front-mount mower · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Weight
183 kg
Hover a source tag to verify
Overview
ManufacturerBolensReference
Front-mount mowerReference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station.Reference
Engine
11HP Briggs & Stratton 399cc 1-cyl gasolineReference
Fuel tank2.8 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement24.4 ciReference
Bore/Stroke87 x 67 mmReference
Power (gross)8.2 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
5-speed gearReference
TransmissionPeerlessReference
TypegearReference
Gears5 forward and 1 reverseReference
Dimensions
Weight183 kgReference
Front tire16x6.50-8Reference
Rear tire13x5.00-6Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear13x5.00-6Reference
Length203 cmReference
Width114 cmReference
Height (steering wheel)102 cmReference
Bolens 936 attachments
36" front-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps5Reference
Battery CCA160Reference
Battery volts12Reference
36" Mower deck
Typefront-mount BolensReference
Type2-bladeReference
Cutting width91 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
