Branson 2205h
Branson 2205h — 05 Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
650 kg
Hover a source tag to verify
Overview
ManufacturerBranson (a part of Kukje)Reference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockmechnanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Yanmar 1.0L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine (gross)16.0 kWReference
Yanmar 3TNM74FReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.0 LReference
Bore/Stroke74 x 77 mmReference
EmissionsTier IVReference
Power (gross)16.0 kWReference
Fuel systemindirect injectionReference
Rated RPM3200Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)11.3 kWReference
Rear valves2Reference
Pump flow15.9 lpmReference
Total flow23.8 lpmReference
Steering flow7.9 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)498 kgReference
Rear lift (at 24"/610mm)307 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTO Type2500Reference
Dimensions
Wheelbase134 cmReference
Weight650 kgReference
Lawn/turf front18x8.50-10Reference
Lawn/turf rear26x12.00-12Reference
Industrial front18x8.50-10Reference
Industrial rear26x12.00-12Reference
Length239 cmReference
Width113 cmReference
Height (ROPS)219 cmReference
Ground clearance21 cmReference
Branson 2205h attachments
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery volts12Reference
Branson BH90 Backhoe
Backhoe typeBranson BH90 BackhoeReference
Transport height170 cmReference
2-Foot flat digging depth167 cmReference
Reach from pivot238 cmReference
Loading height152 cmReference
Bucket Rotation180°Reference
Swing Arc150°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
