Tractor · 2008Unverified
Branson 3110i
Branson 3110i — Kukje built · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
1694 kg
Hover a source tag to verify
Overview
DistributorBransonReference
ManufacturerKukjeReference
Built in Yangsu-ri, South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
ROPS. Canopy optional. Soft cab optional.Reference
Engine
1.6L 3-cyl dieselReference
Fuel tank41.6 LReference
Engine (gross)23.1 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Power (gross)23.1 kWReference
Air cleanerdry elementReference
Pre-heatingblock heater (optional)Reference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
12-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
Four synchronized gears in each of three ranges plus synchronized shuttle.Reference
PTO & Hydraulics
Valves0 to 2Reference
Total flow31.8 lpmReference
Rear TypeIReference
Rear lift (at ends)970 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase165 cmReference
Weight1694 kgReference
Length302 cmReference
Width139 cmReference
Height (ROPS)241 cmReference
Ground clearance27 cmReference
Front tread113 cmReference
Rear tread107 to 145 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
