Tractor · 2016Unverified

Branson 3520CX

Name: Branson 3520CX
Brand: Branson

Branson 3520CX — 20 Series · 29 hp. Reference specifications; pending source verification.

The Branson 3520CX is a compact tractor model, rated at 29 hp, making it suitable for smaller-scale operations. Manufactured between 2016 and 2020, this model features a 3-cylinder diesel liquid-cooled engine, coupled with a four-wheel drive system and a 12-speed gearbox. The tractor's listed weight is 2014 kg, with an intended application for areas up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

29 hp

Weight

2014 kg

Catalogue coverage

Variants represented

Richest spec table

75 rows

Recorded power

29 hp

Recorded weight

2014 kg

Transmissions

12-speed synchronized shuttle

Production years

2016-2020

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerBranson (a part of Kukje)Reference

Compact Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Kukje 1.7L 3-cyl dieselReference

Fuel tank45.4 LReference

Engine26.1 kWReference

Kukje A1700N2Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.7 LReference

Bore/Stroke88 x 94 mmReference

Power26.1 kWReference

Air cleanerdry dual elementReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

PTO & Hydraulics

PTO (claimed)21.6 kWReference

Pump flow33.7 lpmReference

Steering flow18.2 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift1499 kgReference

Rear Armstelescopic lower linksReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Dimensions

Wheelbase180 cmReference

Weight2014 kgReference

Front tire7x16Reference

Rear tire12.4x24Reference

Weight607 kgReference

Standard tires (ag)Front: 7x16. Rear: 12.4x24Reference

Standard tires (ag)Front: 9.5x16. Rear: 12.4x28Reference

Standard tires (ag)Front: 9.5x16. Rear: 14.9x24Reference

Lawn/turf front27x8.5x15Reference

Lawn/turf front29x12.5x15Reference

Lawn/turf rear41x14x20Reference

Lawn/turf rear44x18x20Reference

Industrial front28x8.50-15Reference

Industrial front10x16.5Reference

Industrial front12x16.5Reference

Industrial rear43x16-20Reference

Industrial rear420/70x24Reference

Industrial rear16.9x24Reference

Length331 cmReference

Height (cab)236 cmReference

Ground clearance33 cmReference

Front tread128 cmReference

Rear tread110 to 152 cmReference

Branson 3520CX attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps70Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Branson BH760 Backhoe

Backhoe typeBranson BH760 BackhoeReference

Transport height216 cmReference

Bucket width40 cmReference

Digging depth231 cmReference

Reach from pivot313 cmReference

Loading height228 cmReference

Bucket Rotation149°Reference

Swing Arc180°Reference

Bucket force2065 kgReference

Dipperstick force1147 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
