Tractor · 2021Unverified
Branson 3620H
Branson 3620H — Compact Utility tractor · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1684 kg
Hover a source tag to verify
Overview
ManufacturerBranson (a part of TYM)Reference
Compact Utility tractorReference
Four-wheel driveReference
Two-post folding ROPS.Reference
Variants
3620RshuttleReference
3620HhydrostaticReference
Engine
Kukje 1.7L 3-cyl dieselReference
Fuel tank44.7 LReference
Engine26.1 kWReference
KukjeReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke88 x 94 mmReference
EmissionsTier IVReference
Power26.1 kWReference
Air cleanerdual dryReference
Rated RPM2600Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (4-range)Reference
PTO & Hydraulics
PTO (claimed)22.1 kWReference
Pump flow51.9 lpmReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM584@2600Reference
Dimensions
Wheelbase180 cmReference
Weight1684 kgReference
Front tire9.5-16Reference
Rear tire12.4-28Reference
Standard tires (ag)Front: 9.5-16. Rear: 12.4-28Reference
Lawn/turf front29x12.5-15Reference
Lawn/turf rear44x18.00-20Reference
Industrial front10-16.5Reference
Industrial rear420/70-24Reference
Length323 cmReference
Width164 cmReference
Height (ROPS)249 cmReference
Ground clearance39 cmReference
Branson 3620H attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
Branson BH250 Backhoe
Backhoe typeBranson BH250 BackhoeReference
Transport height231 cmReference
2-Foot flat digging depth262 cmReference
Reach from pivot341 cmReference
Loading height234 cmReference
Bucket Rotation151°Reference
Swing Arc180°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
