Tractor · 2021Unverified

Branson 4820H

Name: Branson 4820H
Brand: Branson

Branson 4820H — Compact Utility tractor · 36 hp. Reference specifications; pending source verification.

The Branson 4820H is a 36 hp tractor, making it a compact option in its class. Manufactured from 2021 to 2025, this model features a 4-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system with a hydrostatic transmission. The tractor's listed weight is 1737 kg and is suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

36 hp

Weight

1737 kg

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

36 hp

Recorded weight

1737 kg

Transmissions

hydrostatic

Production years

2021-2025

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerBranson (a part of TYM)Reference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post folding ROPS.Reference

Variants

4820RROPS shuttleReference

4820HROPS hydrostaticReference

4820CCab shuttleReference

4820CHCab hydrostaticReference

Engine

Kukje 2.3L 4-cyl dieselReference

Fuel tank44.7 LReference

Engine35.8 kWReference

KukjeReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.3 LReference

Bore/Stroke88 x 94 mmReference

EmissionsTier IVReference

Power35.8 kWReference

Air cleanerdual dryReference

Rated RPM2600Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (4-range)Reference

PTO & Hydraulics

PTO (claimed)26.8 kWReference

Pump flow57.9 lpmReference

Steering flow18.9 lpmReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM584@2600Reference

Dimensions

Wheelbase180 cmReference

Weight1737 kgReference

Front tire9.5-16Reference

Rear tire14.9-24Reference

Standard tires (ag)Front: 9.5-16. Rear: 14.9-24Reference

Lawn/turf front29x12.5-15Reference

Lawn/turf rear44x18.00-20Reference

Industrial front10-16.5Reference

Industrial rear16.9-24Reference

Length323 cmReference

Width164 cmReference

Height (ROPS)249 cmReference

Ground clearance39 cmReference

Branson 4820H attachments

front-end loaderReference

backhoeReference

Attachment overview

Front-end loaderReference

BackhoeReference

Branson BH250 Backhoe

Backhoe typeBranson BH250 BackhoeReference

Transport height231 cmReference

2-Foot flat digging depth262 cmReference

Reach from pivot341 cmReference

Loading height234 cmReference

Bucket Rotation151°Reference

Swing Arc180°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
