Tractor · 2006Unverified

Branson 5530C

Name: Branson 5530C
Brand: Branson

Branson 5530C — Kukje built · 55 hp. Reference specifications; pending source verification.

The Branson 5530C tractor has a rated power output of 55 hp, positioning it in the lighter segment of its class. Manufactured in 2006, this tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, coupled with a four-wheel drive system and a hydrostatic transmission. Its listed operating weight is 2517 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Weight

2517 kg

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

55 hp

Recorded weight

2517 kg

Transmissions

24-speed synchronized shuttle

Production years

2006-2006

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorBransonReference

ManufacturerKukjeReference

Built in Yangsu-ri, South KoreaReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Cab with heat and air.Reference

Variants

5530RROPSReference

5530CcabReference

Engine

Kukje 2.3L 4-cyl dieselReference

Fuel tank90.8 LReference

Engine (gross)41.0 kWReference

Kukje A2300T2-ATCReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.3 LReference

Bore/Stroke88 x 94 mmReference

Power (gross)41.0 kWReference

Air cleanerdual dry elementReference

Pre-heatingblock heater (optional)Reference

Compression21.3:1Reference

Rated RPM2600Reference

Starter typeelectricReference

Transmission

24-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears24 forward and reverseReference

PTO & Hydraulics

PTO (claimed)35.0 kWReference

Rear TypeIIReference

Rear lift (at ends)1330 kgReference

Rear PTOindependentReference

Rear PTO Type540/680/1000Reference

Dimensions

Wheelbase203 cmReference

Weight2517 kgReference

Front tire11.2-20Reference

Rear tire14.9-30Reference

Ag front11.2-20Reference

Ag rear14.9-30Reference

Length364 cmReference

Width175 cmReference

Height (ROPS)248 cmReference

Ground clearance35 cmReference

Front tread125 to 162 cmReference

Rear tread127 to 155 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
