Tractor · 2006Unverified
Branson 5530R
Branson 5530R — Kukje built · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
2308 kg
Hover a source tag to verify
Overview
DistributorBransonReference
ManufacturerKukjeReference
Built in Yangsu-ri, South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
ROPS. Canopy optional.Reference
Variants
5530RROPSReference
5530CcabReference
Engine
Kukje 2.3L 4-cyl dieselReference
Fuel tank90.8 LReference
Engine (gross)41.0 kWReference
Kukje A2300T2-ATCReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke88 x 94 mmReference
Power (gross)41.0 kWReference
Air cleanerdual dry elementReference
Pre-heatingblock heater (optional)Reference
Compression21.3:1Reference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
24-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)35.0 kWReference
Rear TypeIIReference
Rear lift (at ends)1330 kgReference
Rear PTOindependentReference
Rear PTO Type540/680/1000Reference
Dimensions
Wheelbase203 cmReference
Weight2308 kgReference
Front tire11.2-20Reference
Rear tire14.9-30Reference
Ag front11.2-20Reference
Ag rear14.9-30Reference
Length364 cmReference
Width175 cmReference
Height (ROPS)248 cmReference
Ground clearance35 cmReference
Front tread125 to 162 cmReference
Rear tread127 to 155 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
