The Branson 7845R is a tractor with a rated power output of 64 hp, positioning it at the lighter end of its class. This model was in production from 2016 to 2023. It features a 4-cylinder turbocharged diesel liquid-cooled engine, teamed with four-wheel drive and a 16-speed gearbox. The Branson 7845R has an operating weight of 2609 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
2609 kg
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
64 hp
Recorded weight
2609 kg
Transmissions
16-speed sychronized shuttle
Production years
2016-2023
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerBranson (a part of Kukje)Reference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Variants
7845RROPSReference
7845CCabReference
Engine
Kukje 3.4L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine58.2 kWReference
Kukje D3400T1-UTR-3Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke98 x 113 mmReference
Power58.2 kWReference
Air cleanerdry dual elementReference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed sychronized shuttleReference
Typesychronized shuttleReference
Gears16 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
PTO (claimed)47.7 kWReference
Pump flow46.9 lpmReference
Steering flow31.4 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear Armstelescopic lower linksReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000Reference
Dimensions
Wheelbase219 cmReference
Weight2609 kgReference
Front tire11.2x24Reference
Rear tire16.9x30Reference
Standard tires (ag)Front: 11.2x24. Rear: 16.9x30Reference
Length387 cmReference
Height (ROPS)260 cmReference
Height (cab)273 cmReference
Ground clearance46 cmReference
Branson 7845R attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps70Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
