Tractor · 2012Unverified
Branson 8050
Branson 8050 — 50 Series · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
3587 kg
Hover a source tag to verify
Overview
ManufacturerBransonReference
Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Kukje 3.4L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine58.2 kWReference
Kukje D3400T5Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke98 x 113 mmReference
Power58.2 kWReference
Air cleanerdryReference
Pre-heatingair heaterReference
Compression18.5:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed syncro shuttleReference
Typesyncro shuttleReference
Gears16 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Typeopen centerReference
Mid valves2Reference
Pump flow54.9 lpmReference
Steering flow30.3 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2268 kgReference
Rear PTOindependentReference
Rear PTO Type540/760 (1.375)Reference
Dimensions
Wheelbase223 cmReference
Weight3587 kgReference
Front tire11.2R24Reference
Rear tire18.4R30Reference
Ag front11.2R24Reference
Ag rear18.4R30Reference
Length398 cmReference
Width193 cmReference
Height269 cmReference
Ground clearance42 cmReference
Front tread182 cmReference
Rear tread182 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
