Tractor · 2000Unverified
Buhler Versatile 2180
Buhler Versatile 2180 — Genesis Series · 186 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
186 hp
Max power
149.6 kW
Weight
8711 kg
Hover a source tag to verify
Overview
ManufacturerBuhler VersatileReference
Row-Crop tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Original price was $110,000 in 2008Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
8870similar Ford modelReference
Engine
New Holland 7.5L 6-cyl dieselReference
Engine193.9 kWReference
Drawbar (tested)124.0 kWReference
New Holland GenesisReference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement7.5 LReference
Bore/Stroke112 x 127 mmReference
EmissionsTier IIReference
Power193.9 kWReference
Fuel systemelectronic fuel injectionReference
Air cleanerdual paper elementsReference
Compression17.5:1Reference
Rated RPM2100Reference
Starter volts12Reference
Oil capacity21.3 LReference
Coolant capacity26.5 LReference
Max power149.6 kWReference
Power at rated engine speed138.6 kWReference
Max power124.0 kWReference
Transmission
16-speed full power shiftReference
18-speed full power shiftReference
Typefull power shiftReference
Gears16 forward and 9 reverseReference
Clutchelectro-hydraulic wet discReference
ManufacturerFunkReference
Gears18 forward and 9 reverseReference
PTO & Hydraulics
PTO (claimed)134.2 kWReference
PTO (tested)149.6 kWReference
Hydraulic system140.0 LReference
Typeclosed center load-sensingReference
Capacity140.0 LReference
Pressure200.0 barReference
Valves3 or 4Reference
Total flow113.6 lpmReference
Total flow208.2 lpmReference
Rear TypeIIIReference
Controlelectronic draft sensingReference
Rear lift5670 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type1000 (1.75)Reference
Rear PTO Type1000 (1.375)Reference
Engine RPM1000@1903Reference
Power at rated PTO speed149.3 kWReference
Capacities
Fuel416.4 LReference
Dimensions
Standard Steer Wheelbase300 cmReference
Ultra Steer Wheelbase311 cmReference
Weight8711 kgReference
Front tire16.9R30Reference
Rear tire20.8R42Reference
Ag front16.9R30Reference
Ag rear20.8R42Reference
Standard Steer Length511 cmReference
Ultra Steer Length522 cmReference
Width284 cmReference
Height (cab)309 cmReference
Height (exhaust)314 cmReference
Ground clearance47 cmReference
Rear axle104 by 2844 mmReference
Rear axle104 by 3048 mmReference
2WD Front tread154 to 220 cmReference
4WD Front tread152 to 223 cmReference
Rear tread152 to 314 cmReference
Rear tread152 to 325 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps130Reference
Batteries2Reference
Battery CCA950Reference
Battery volts12Reference
Test results
Diesel 16-speed 4WDMay 1996 - July 1996, Link: OCED Tractor Test 1647 fileReference
PTO performanceReference
Fuel use37.9 l/hourReference
Fuel use38.2 l/hourReference
Fuel use38.6 l/hourReference
Drawbar performanceReference
Fuel use39.4 l/hourReference
Gear 9 used for power test.Reference
Max pull8414 kgReference
Gear 5 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
