Tractor · 2008Unverified

Buhler Versatile 305

Name: Buhler Versatile 305
Brand: Buhler Versatile

Buhler Versatile 305 — Four-wheel Drive (4WD) tractor · 305 hp. Reference specifications; pending source verification.

The Buhler Versatile 305 is a high-powered tractor model, rated at 305 hp, positioning it among the more powerful machines in its class. It was manufactured from 2008 to 2010. The tractor is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, which drives the four-wheel drive system via a powershift transmission. The listed weight of the Buhler Versatile 305 is 14,515 kg, and it is designed for use on large areas, typically exceeding 1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

305 hp

Weight

14515 kg

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

305 hp

Recorded weight

14515 kg

Transmissions

12-speed partially synchronized

Production years

2008-2010

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerBuhler VersatileReference

Four-wheel Drive (4WD) tractorReference

Built in Winnipeg, Manitoba, CanadaReference

Four-wheel driveReference

Final drivesoutboard planetaryReference

Differential lockoptionalReference

Brakessingle dry caliper standardReference

Brakesdual dry caliper optionalReference

Cab standard with heat and A/CReference

Engine

Cummins 10.8L 6-cyl dieselReference

Engine227.4 kWReference

Cummins QSM11Reference

turbocharged aftercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement10.8 LReference

Bore/Stroke125 x 147 mmReference

Power227.4 kWReference

Torque1423.8 NmReference

Torque RPM1400Reference

Oil capacity36.7 LReference

Coolant capacity54.9 LReference

Transmission

12-speed partially synchronizedReference

12-speed powershiftReference

Typepartially synchronizedReference

Gears12 forward and 4 reverseReference

Four synchronized gears in each of three ranges.Reference

TypepowershiftReference

Gears12 forward and 2 reverseReference

Capacities

Fuel946.2 LReference

PTO & Hydraulics

Hydraulic system75.7 LReference

Typeclosed center load sensingReference

Capacity75.7 LReference

Pressure200.0 barReference

Valves4 to 6Reference

Total flow189.2 lpmReference

Total flow283.9 lpmReference

Rear Type3/4N optionalReference

Rear lift5896 kgReference

Rear PTOoptionalReference

Rear PTO Type1000Reference

Dimensions

Wheelbase360 cmReference

Weight14515 kgReference

Length698 cmReference

Height (cab)363 cmReference

Height (exhaust)370 cmReference

Shipping weight14515 kgReference

Max weight15422 kgReference

Ground clearance42 cmReference

Electrical

Charging systemalternatorReference

Charging amps160Reference

Batteries3Reference

Battery CCA950Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
