Tractor · 1991Unverified
Buhler Versatile 9030
Buhler Versatile 9030 · 102 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
102 hp
Weight
4604 kg
Hover a source tag to verify
Overview
ManufacturerBuhler VersatileReference
Built in Winnipeg, Manitoba, CanadaReference
Four-wheel driveReference
Cab with heat and A/C. Console rotates 180-degrees.Reference
Variants
9030similar Ford modelReference
Engine
Ford 4.4L 4-cyl dieselReference
Ford BSD444TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke112 x 112 mmReference
Compression17.1:1Reference
Rated RPM2500Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Intake valve clearance0.381 mmReference
Exhaust valve clearance0.457 mmReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)76.1 kWReference
Dimensions
Wheelbase203 cmReference
Weight4604 kgReference
Length457 cmReference
Length492 cmReference
Width206 cmReference
Height (cab)290 cmReference
Height (exhaust)297 cmReference
Shipping weight4604 kgReference
Ground clearance41 cmReference
9030 Serial Numbers
1991470100Reference
1992487501Reference
1993932000Reference
1994200000Reference
1995201023Reference
1996201894Reference
1997202423Reference
1992488038 (yellow)Reference
1993932050 (yellow)Reference
1994200095 (yellow)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
