Tractor · 2014Unverified
Cabelas LM25
Cabelas LM25 — LM Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
730 kg
Hover a source tag to verify
Overview
DistributorCabelasReference
ManufacturerTYMReference
Sub-Compact Utility tractorReference
Built in South KoreaReference
Original price was $13,999 in 2016Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Yanmar 1.3L 3-cyl dieselReference
Engine (gross)17.9 kWReference
Yanmar 3TNV80FReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke80 x 84 mmReference
Power (gross)17.9 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dry elementReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.8 LReference
Coolant capacity4.0 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity14.5 LReference
PTO & Hydraulics
PTO (claimed)13.0 kWReference
Hydraulic system14.4 LReference
Typeopen centerReference
Capacity14.4 LReference
Pump flow17.0 lpmReference
Total flow26.9 lpmReference
Steering flow10.0 lpmReference
Rear TypeINReference
Controlposition controlReference
Rear lift (at ends)600 kgReference
Rear lift (at 24"/610mm)449 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Capacities
Fuel20.1 LReference
Front axle3.5 LReference
Dimensions
Wheelbase1460 cmReference
Weight730 kgReference
Industrial front20x8.0-10Reference
Industrial rear27x12.5-15Reference
Length256 cmReference
Width116 cmReference
Height (ROPS)233 cmReference
Ground clearance24 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
