Tractor · 2014Unverified
Cabelas LM36
Cabelas LM36 — LM Series · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Hover a source tag to verify
Overview
DistributorCabelasReference
ManufacturerTYMReference
Compact Utility tractorReference
Built in South KoreaReference
Original price$19,999 (2016 gear )Reference
Original price$22,199 (2016 hydro )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
LM36shuttleReference
LM36HhydrostaticReference
Engine
Yanmar 1.6L 3-cyl dieselReference
Fuel tank34.1 LReference
Engine (gross)25.5 kWReference
YanmarReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke88 x 90 mmReference
Power (gross)25.5 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed shuttleReference
hydrostaticReference
TypeshuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)21.0 kWReference
Hydro PTO (claimed)20.0 kWReference
Typeopen centerReference
Rear TypeIReference
Rear lift1200 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
