Tractor · 2014Unverified
Cabelas LM55
Cabelas LM55 — LM Series · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
3924 to 4415 pounds
Hover a source tag to verify
Overview
DistributorCabelasReference
ManufacturerTYMReference
Compact Utility tractorReference
Built in South KoreaReference
Original price$29,499 (2016 gear ROPS )Reference
Original price$31,799 (2016 hydro ROPS )Reference
Original price$36,399 (2016 hydro cab )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab available with air-conditioning.Reference
Variants
LM55shuttle ROPSReference
LM55Hhydrostatic ROPSReference
LM55HChydrostatic cabReference
Engine
Yanmar 2.1L 4-cyl dieselReference
Engine (gross)41.1 kWReference
Yanmar 4TNV86T-CRReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke86 x 90 mmReference
Emission controldiesel oxidation catalyst with diesel particulate filterReference
Power (gross)41.1 kWReference
Fuel systemcommon rail direct injectionReference
Air cleanerdual dry elementReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.7 LReference
Coolant capacity8.5 LReference
Transmission
16-speed synchronized shuttleReference
hydrostaticReference
Gear ROPS Shipping1779 kgReference
Typesynchronized shuttleReference
Gears16 forward and reverseReference
Clutchdry discReference
Oil capacity35.0 LReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)33.5 kWReference
Hydro PTO (claimed)31.5 kWReference
Hydraulic system35.0 LReference
Typeopen centerReference
Capacity35.0 LReference
Valves1Reference
Pump flow36.0 lpmReference
Total flow54.9 lpmReference
Steering flow18.9 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1503 kgReference
Rear lift (at 24"/610mm)1335 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Capacities
Fuel64.3 LReference
Front axle9.9 LReference
Dimensions
Wheelbase193 cmReference
Weight3924 to 4415 poundsReference
Front tire9.5-16Reference
Rear tire14.9-24Reference
Standard tires (ag)Front: 9.5-16. Rear: 14.9-24Reference
Industrial front12-16.5Reference
Industrial rear16.9-24Reference
Length358 cmReference
Width162 cmReference
Height (ROPS)259 cmReference
Height (cab)252 cmReference
Ground clearance35 cmReference
Hydro ROPS Shipping1779 kgReference
Hydro cab Shipping1920 kgReference
Hydro cab Operating2002 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery volts12Reference
Test results
Diesel hydrostatic 4WDAugust 20 - September 3, 2015Link: Nebraska Tractor Test 2127 fileReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
