Tractor · 1976Unverified
Cameco 345-B
Cameco 345-B — Four-wheel Drive (4WD) tractor · 250 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
250 hp
Weight
10614 kg
Hover a source tag to verify
Overview
ManufacturerCamecoReference
Four-wheel Drive (4WD) tractorReference
Built in Thibodaux, Louisiana, USAReference
Four-wheel driveReference
Final drivesinboard planetaryReference
Hydraulic wet discs brakesReference
Trailer brakesair brakes (optional)Reference
Open operator station. Cab available with air-conditioning.Reference
Engine
Caterpillar 10.5L 6-cyl dieselReference
John Deere 6-cyl dieselReference
Engine186.4 kWReference
Caterpillar 3306DITReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement10.5 LReference
Bore/Stroke121 x 152 mmReference
Power186.4 kWReference
Rated RPM2200Reference
Torque833.9 NmReference
Torque RPM1500Reference
Firing order1-5-3-6-2-4Reference
StarterelectricReference
Starter volts24Reference
Oil capacity28.4 LReference
John Deere 6081Reference
The John Deere 6081 replaced the Caterpillar 3306 in 2003.Reference
Torque1095.6 NmReference
Torque RPM1400Reference
Transmission
11-speed power shiftReference
10-speedReference
Typepower shiftReference
Gears11 forward and 3 reverseReference
Oil capacity22.7 LReference
TransmissionAllisonReference
Gears10 forward and 2 reverseReference
Five speed tranmission with torque converter and two-speed transfer case.Reference
Capacities
Fuel378.5 LReference
PTO & Hydraulics
Hydraulic system215.7 LReference
Typeopen centerReference
Capacity215.7 LReference
Pressure137.9 barReference
Valves2 to 5Reference
Pump flow94.6 lpmReference
Rear TypeIIIReference
Dimensions
Weight10614 kgReference
Front tire23.1x30Reference
Rear tire23.1x30Reference
Ag front23.1x30Reference
Ag rear23.1x30Reference
Ag front23.1x26Reference
Ag front20.8x38Reference
Ag front24.5x38Reference
Ag front24.5x32Reference
Ag rear23.1x26Reference
Ag rear20.8x38Reference
Ag rear24.5x38Reference
Ag rear24.5x32Reference
Shipping weight10614 kgReference
Ground clearance50 cmReference
Electrical
Charging systemalternatorReference
Charging amps130Reference
Charging amps140Reference
Batteries2Reference
Battery CCA925Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
