Tractor · 1980Unverified
Cameco 505
Cameco 505 — Four-wheel Drive (4WD) tractor · 325 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
325 hp
Weight
12723 kg
Hover a source tag to verify
Overview
ManufacturerCamecoReference
Four-wheel Drive (4WD) tractorReference
Built in Thibodaux, Louisiana, USAReference
Four-wheel driveReference
Cab standrd.Reference
Engine
Caterpillar 14.6L 6-cyl dieselReference
Fuel tank492.1 LReference
Engine242.4 kWReference
Caterpillar 3406TReference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.6 LReference
Bore/Stroke137 x 165 mmReference
Power242.4 kWReference
Fuel systemturbochargedReference
Rated RPM2100Reference
Idle RPM700-2350Reference
Torque1376.3 NmReference
Torque RPM1200Reference
Firing order1-5-3-6-2-4Reference
Starter typeelectricReference
Oil capacity37.6 LReference
Coolant capacity61.0 LReference
Transmission
10-speed power shiftReference
TransmissionAllison HT 754Reference
Typepower shiftReference
Gears10 forward and 2 reverseReference
Oil capacity9.7 LReference
Oil capacity15.0 LReference
Five-speed Allison transmission with torque converter and two-speed Cameco transfer case.Reference
Dimensions
Weight12723 kgReference
Front tire24.5x32Reference
Rear tire24.5x32Reference
Ag front24.5x32Reference
Ag rear24.5x32Reference
Width271 cmReference
Height (cab)350 cmReference
Shipping weight12723 kgReference
Speeds
With 24.5x32 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
