Tractor · 2003Unverified
Captain 2600 DI
Captain 2600 DI — Compact Utility tractor · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
1863 to 1995 pounds
Hover a source tag to verify
Overview
ManufacturerCaptainReference
Compact Utility tractorReference
Built in Rajkot, IndiaReference
Two- or four-wheel driveReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
FM 0.6L 1-cyl dieselReference
Fuel tank15.1 LReference
Engine8.8 kWReference
FMReference
dieselReference
1-cylinderReference
air-cooledReference
Displacement0.6 LReference
Bore/Stroke85 x 110 mmReference
Power8.8 kWReference
Air cleaneroil bathReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.8 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Four gears, plus reverse, in two ranges.Reference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase154 cmReference
Weight1863 to 1995 poundsReference
Front tire5.20-14Reference
2WD Rear tire8.00-18Reference
2WD Standard tires (ag)Front: 5.20-14. Rear: 8.00-18Reference
4WD Standard tires (ag)Front: 5.00-12. Rear: 8.00-18Reference
Length263 cmReference
Width116 cmReference
Height (exhaust)194 cmReference
2WD Weight845 kgReference
4WD Weight904 kgReference
Ground clearance24 cmReference
Rear tread82 to 95 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
