Tractor · 2021Unverified
Captain 263
Captain 263 — Compact Utility tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
928 kg
Hover a source tag to verify
Overview
ManufacturerCaptainReference
Compact Utility tractorReference
Built in Rajkot, IndiaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Engine18.2 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
Power18.2 kWReference
Air cleanerdryReference
Rated RPM2500Reference
Torque76.3 NmReference
Torque RPM2000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.7 LReference
Transmission
9-speed partially synchronizedReference
Typepartially synchronizedReference
Gears9 forward and 3 reverseReference
Oil capacity20.0 LReference
Three gears, plus reverse, in three ranges.Reference
Capacities
Fuel20.1 LReference
PTO & Hydraulics
Hydraulic system20.1 LReference
Capacity20.1 LReference
Rear TypeINReference
Rear lift749 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2300Reference
Engine RPM1000@2305Reference
Dimensions
Wheelbase149 cmReference
Weight928 kgReference
Front tire5.00-12Reference
Rear tire8.00-18Reference
Standard tires (ag)Front: 5.00-12. Rear: 8.00-18Reference
Lawn/turf front23x8.50-12Reference
Lawn/turf rear33x15.5-16Reference
Length284 cmReference
Width104 cmReference
Height (ROPS)205 cmReference
Ground clearance17 cmReference
Rear tread74 to 98 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
With 8.3-20 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
