Maxxum Series · 2024 Case IH Maxxum 125 Case IH Maxxum 125: 125 hp tractor — 6.7 L engine, 105 hp PTO, 3406 kg rear lift. Verified specs with sources, UK & US units.
The Case IH Maxxum 125 is a tractor with a rated power of 125 hp, which puts it at the powerful end of its class. The Maxxum 125 entered production in 2024. Under the hood is a diesel engine, paired with two-wheel drive with a powershift transmission. It has a listed operating weight of 5,160.1 kg, and it suits operations of 200–800 ac. Recorded specifications in UK and US units are listed below.
Richest spec table
27 rows
1 linked source document displayed
Specifications Description Maintenance Troubleshooting Ownership Reviews Q&A Docs & sources
Hover a source tag to verify UK metric US imperial
Rated power 93 kW (125 hp) OEM
Emissions stage Stage V EPA cert
Engine 6.7 L Dealer
Fuel Type Diesel Reference
Hydraulic flow 63 L/min Dealer
PTO power 78 kW (105 hp) Dealer
Rear lift capacity 3406 kg Dealer
Fuel tank 250 L Dealer
Capacity 4.5 L Reference
Diesel exhaust fluid (DEF) tank 31.4 L Reference
Make & Model Case IH FPT Reference
SCV control Joystick: Available Reference
Rear PTO RPM 1,000 Reference
Front PTO Power Available Reference
Transmission Type Powershift Reference
forward and reverse options 23Fx23R Reference
Wheel Drive 2WD Reference
Remote Valves 4 Reference
Rear Hitch category (SAE designation) Category 2 Reference
Wheelbase 264.2 cm Reference
Height Over Cab Option 1: 84.6 inches\\nOption 2: 2,150 mm Reference
Overall Width 248.9 cm Reference
Overall weight 5,160.1 kg Reference
Weight 8,999.7 kg Reference
Cab Availability TRUE Reference
Seat Suspension Available Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
