Tractor · 1985Unverified

CaseIH 2096

Name: CaseIH 2096
Brand: CaseIH

CaseIH 2096 — 96 Series · 116 hp. Reference specifications; pending source verification.

The CaseIH 2096 is a tractor model with a power rating of approximately 116 hp, falling within the mid-range category for its class. Produced from 1985 to 1989, this model is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive, paired with a powershift transmission. Its operating weight ranges from 11875 to 14180 pounds. It is suitable for operations covering areas of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

116 hp

Max power

75.0 kW

Weight

11875 to 14180 pounds

Catalogue coverage

Variants represented

Richest spec table

89 rows

Recorded power

116 hp

Transmissions

12-speed three-speed power shift

Production years

1985-1989

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Row-Crop tractorReference

Built in Racine, Wisconsin, USAReference

Original price was $40,000 in 1989Reference

The Case 2096 was sold in both red and white paint. The 2096 was in production at the time of the merger between J.I. Case and International Harvester. White painted tractors were produced prior to the merger.Reference

Two- or four-wheel driveReference

Differential lockelectric rearReference

Power steeringReference

Differential hydraulic wet discs brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

CDC 5.9L 6-cyl dieselReference

Drawbar (claimed)75.3 kWReference

Drawbar (tested)75.0 kWReference

CDCReference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement5.9 LReference

Bore/Stroke102 x 120 mmReference

Air cleanerdual paper elementsReference

Compression16.5:1Reference

Rated RPM2100Reference

Idle RPM800-2250Reference

Starter volts12Reference

Oil capacity15.1 LReference

Coolant capacity20.8 LReference

Power at rated engine speed86.3 kWReference

Max power75.0 kWReference

Transmission

12-speed three-speed power shiftReference

Typethree-speed power shiftReference

Gears12 forward and 3 reverseReference

Oil capacity94.6 LReference

Three power shift gears, plus reverse, in four ranges. Reverse is not operable in range four.Reference

PTO & Hydraulics

PTO (claimed)86.5 kWReference

PTO (tested)86.3 kWReference

Hydraulic system94.6 LReference

Typeclosed centerReference

Capacity94.6 LReference

Pressure155.1 barReference

Valves2Reference

Pump flow87.1 lpmReference

Steering flow30.3 lpmReference

Rear TypeIIReference

Rear lift (at 24"/610mm)3742 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000 (1.375)Reference

Capacities

Fuel246.0 LReference

Dimensions

Wheelbase274 cmReference

Weight11875 to 14180 poundsReference

Front tire11.00-16Reference

2WD Rear tire18.4-38Reference

2WD Standard tires (ag)Front: 11.00-16. Rear: 18.4-38Reference

4WD Standard tires (ag)Front: 16.9-26. Rear: 18.4-38Reference

Length434 cmReference

Ground clearance40 cmReference

Bar rear axle88 by 2438 mmReference

Bar rear axle88 by 3048 mmReference

2WD Front tread152 to 223 cmReference

4WD Front tread152 to 226 cmReference

Rear tread152 to 279 cmReference

Rear tread152 to 335 cmReference

Shipping5386 kgReference

Shipping5930 kgReference

Operating6432 kgReference

2096 Serial Numbers

Location:Inside cab the rear window or doorReference

19849931800Reference

19859938100Reference

19869941573Reference

198717897512Reference

198817897658Reference

198917898172Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps105Reference

Battery volts12Reference

CaseIH 2096 Height

ROPS293 cmReference

Height (Folded ROPS)232 cmReference

Cab299 cmReference

Exhaust294 cmReference

Test results

Diesel 12-speed 2WDOctober 24 - November 5, 1984Link: Nebraska Tractor Test 1549 fileReference

PTO performanceReference

Fuel use25.4 l/hourReference

Drawbar performanceReference

Fuel use25.0 l/hourReference

Gear 3-2 used for power test.Reference

Max pull5858 kgReference

Gear 1-2 used for pull test.Reference

Speeds

With 18.4x38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
