Tractor · 1985Unverified
CaseIH 234
CaseIH 234 — 200 Series · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
635 kg
Hover a source tag to verify
Overview
DistributorCaseIHReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Original price was $7,100 in 1986Reference
Two- or four-wheel driveReference
Engine
Mitsubishi 0.8L 3-cyl dieselReference
MitsubishiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke68 x 78 mmReference
Rated RPM2700Reference
Oil capacity3.0 LReference
Coolant capacity4.9 LReference
Transmission
6-speed gearReference
hydrostaticReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity11.7 LReference
Three gears plus reverse with high and low ranges.Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)11.3 kWReference
Rear TypeIReference
Rear PTO Type540Reference
Dimensions
Weight635 kgReference
Front tire4.5-10Reference
Rear tire8-18Reference
Ag front4.5-10Reference
Ag rear8-18Reference
234 Serial Numbers
Location:Tractor frame, front-right side.Reference
19859405Reference
198610454Reference
FAQ: How to read a serial number table.Reference
Speeds
With 8.00-18 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
