Tractor · 1986Unverified
CaseIH 235
CaseIH 235 — 200 Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
1350 to 1537 pounds
Hover a source tag to verify
Overview
DistributorCaseIHReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Original price was $10,000 in 1990Reference
Two- or four-wheel driveReference
Mechanical drum brakesReference
Two-post folding ROPS. Optional canopy.Reference
Engine
Mitsubishi 0.8L 3-cyl dieselReference
Engine (net)13.4 kWReference
MitsubishiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.8 LReference
Bore/Stroke68 x 78 mmReference
Power (net)13.4 kWReference
Air cleanerdry type cycloneReference
Rated RPM2700Reference
Starter volts12Reference
Oil capacity3.0 LReference
Coolant capacity4.9 LReference
Transmission
6-speedReference
hydrostaticReference
Gear 2WD Shipping612 kgReference
Gear 4WD Shipping662 kgReference
Gears6 forward and 2 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (two-range)Reference
PTO & Hydraulics
PTO (claimed)11.3 kWReference
Hydraulic system11.7 LReference
Capacity11.7 LReference
Valves0 or 1Reference
Total flow12.9 lpmReference
Rear TypeIReference
Rear lift (at ends)469 kgReference
Rear lift (at 24"/610mm)370 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOliveReference
Rear PTO Type540Reference
Mid PTOliveReference
Mid PTO Type2400Reference
Front PTO Type2700Reference
Capacities
Fuel18.2 LReference
Dimensions
Wheelbase142 cmReference
Weight1350 to 1537 poundsReference
Front tire4.50-10Reference
Rear tire8.00-18Reference
2WD Ag front4.50-10Reference
4WD Ag front5.00-12Reference
Ag rear8.00-18Reference
2WD Ag front5.00-10Reference
4WD Ag front6-12Reference
Ag rear9.5-16Reference
2WD Lawn/turf front18x7.00-8Reference
2WD Lawn/turf front20x8.00-10Reference
4WD Lawn/turf front20.5x8.00-10Reference
4WD Lawn/turf front6-14Reference
Lawn/turf rear31x15.50-15Reference
Lawn/turf rear9.5-18Reference
Length260 cmReference
2WD Width93 cmReference
4WD Width99 cmReference
Ground clearance29 cmReference
2WD Clearance (front axle)27 cmReference
4WD Clearance (front axle)23 cmReference
2WD Front tread71 cmReference
4WD Front tread81 cmReference
Rear tread73 to 88 cmReference
Hydro 2WD Shipping647 kgReference
Hydro 4WD Shipping697 kgReference
2WD Steering wheel121 cmReference
4WD Steering wheel122 cmReference
CaseIH 235 attachments
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
Two mid-mount mower decks were available, the 60MB used the rear PTO while the 60MS used the mid PTO. Also available was the 60FS (rear PTO) and 60FMS (mid PTO) front-mount mowers.Reference
60" Mower deck
Typemid-mount Case IH 60MReference
Type3-blade with hydraulic liftReference
Cutting width152 cmReference
DriveshaftReference
Cut height3 to 10 cmReference
CaseIH 235 Height
ROPS199 cmReference
Speeds
With 8.00-18 rear tiresReference
With 8.00-18 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
