Industrial Tractor · 1985Unverified

CaseIH 248

Name: CaseIH 248
Brand: CaseIH

CaseIH 248 — Industrial tractor · 54 hp. Reference specifications; pending source verification.

The CaseIH 248 is a tractor with a rated power of 54 hp, categorising it as a lighter model within its class. Manufactured between 1985 and 1986, this tractor is equipped with a 3-cylinder diesel liquid-cooled engine and features two-wheel drive with an 8-speed gearbox. The operating weight is listed as 2503 kg, and it is suitable for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

54 hp

Weight

2503 kg

Catalogue coverage

Variants represented

Richest spec table

82 rows

Recorded power

54 hp

Recorded weight

2503 kg

Transmissions

8-speed synchromesh

Production years

1985-1986

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Industrial tractorReference

Built in Doncaster, EnglandReference

Two-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanical rearReference

Power steeringReference

Hydraulic disc brakesReference

Trailer brakeshydraulicReference

Cab standard with available heater.Reference

Variants

495agricultural tractorReference

Engine

CaseIH 2.9L 3-cyl dieselReference

Fuel tank76.8 LReference

Engine (gross)40.0 kWReference

Engine (net)38.8 kWReference

CaseIH D-179Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke98 x 129 mmReference

Power (net)38.8 kWReference

Power (gross)40.0 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Compression15:1Reference

Rated RPM2180Reference

Idle RPM815-2300Reference

Torque181.7 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity6.5 LReference

Coolant capacity11.4 LReference

Transmission

8-speed synchromeshReference

8-speed shuttleReference

TypesynchromeshReference

Gears8 forward and 4 reverseReference

Clutch280mm dry discReference

Oil capacity34.1 LReference

TypeshuttleReference

Gears8 forward and reverseReference

PTO & Hydraulics

PTO (claimed)30.6 kWReference

PTO (claimed)32.5 kWReference

Pressure172.4 barReference

Rear valves2Reference

Pump flow45.0 lpmReference

Steering flow9.8 lpmReference

Steering press.106.9 barReference

Rear TypeII/IReference

Controltop link draft sensingReference

Rear lift1678 kgReference

Rear lift2018 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1936Reference

Dimensions

Wheelbase200 cmReference

Weight2503 kgReference

Front tire6.00-16Reference

Rear tire14.9/13-28Reference

Industrial front6.00-16Reference

Industrial rear14.9/13-28Reference

Industrial front7.50-16Reference

Industrial rear12.4/11-32Reference

Industrial rear14.9/13-24Reference

Length322 cmReference

Height (steering wheel)154 cmReference

Height (cab)231 cmReference

Clearance (front axle)43 cmReference

Clearance (rear axle)55 cmReference

Clearance (drawbar)33 cmReference

Front tread134 to 200 cmReference

Rear tread132 to 193 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Battery CCA420Reference

Battery volts12Reference

Battery AH95Reference

Speeds

With 13-28 rear tires. Low-speed ratio option available.Reference

With 13-28 rear tires. Reverse speeds are 26% faster than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
