Industrial Tractor · 1985Unverified
CaseIH 258
CaseIH 258 — Industrial tractor · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
2721 kg
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Industrial tractorReference
Built in Doncaster, EnglandReference
Two-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic disc brakesReference
Trailer brakeshydraulicReference
Cab standard with available heater.Reference
Variants
595agricultural tractorReference
Engine
CaseIH 3.4L 4-cyl dieselReference
Fuel tank76.8 LReference
Engine (gross)46.2 kWReference
Engine (net)43.9 kWReference
CaseIH D-206Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke98 x 111 mmReference
Power (net)43.9 kWReference
Power (gross)46.2 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression15:1Reference
Rated RPM2300Reference
Idle RPM700-2560Reference
Torque219.7 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity13.7 LReference
Transmission
8-speed synchromeshReference
8-speed shuttleReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Clutch280mm dry discReference
Oil capacity34.1 LReference
TypeshuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)36.7 kWReference
PTO (claimed)39.8 kWReference
Pressure172.4 barReference
Rear valves2Reference
Pump flow45.0 lpmReference
Pump flow68.1 lpmReference
Steering flow9.8 lpmReference
Steering press.106.9 barReference
Rear TypeIIReference
Controltop link draft sensingReference
Rear lift2000 kgReference
Rear lift2381 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2140Reference
Dimensions
Wheelbase214 cmReference
Weight2721 kgReference
Front tire7.50-16Reference
Rear tire16.9/14-28Reference
Industrial front7.50-16Reference
Industrial rear16.9/14-28Reference
Length335 cmReference
Height (steering wheel)160 cmReference
Height (cab)236 cmReference
Clearance (front axle)55 cmReference
Clearance (rear axle)55 cmReference
Clearance (drawbar)33 cmReference
Front tread134 to 200 cmReference
Rear tread152 to 193 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery CCA420Reference
Battery volts12Reference
Battery AH95Reference
Speeds
With 14-28 rear tires. Low-speed ratio option available.Reference
With 14-28 rear tires. Reverse speeds are 26% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
