Industrial Tractor · 1985Unverified
CaseIH 268
CaseIH 268 — Industrial tractor · 72 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
72 hp
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Industrial tractorReference
Built in Doncaster, EnglandReference
Two-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic disc brakesReference
Cab standard with available heater.Reference
Variants
695agricultural tractorReference
Engine
CaseIH 3.9L 4-cyl dieselReference
Engine (gross)53.7 kWReference
Engine (net)50.7 kWReference
CaseIH D-239Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 129 mmReference
Power (net)50.7 kWReference
Power (gross)53.7 kWReference
Air cleanerdryReference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchromeshReference
hydrostaticReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Rear PTOindependentReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
