Industrial Tractor · 1985Unverified
CaseIH 288
CaseIH 288 — Industrial tractor · 84 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
84 hp
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Industrial tractorReference
Built in Doncaster, EnglandReference
Two-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic disc brakesReference
Cab standard with available heater.Reference
Variants
895agricultural tractorReference
Engine
CaseIH 4.4L 4-cyl dieselReference
Engine (gross)62.6 kWReference
Engine (net)58.9 kWReference
CaseIH D-268Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke100 x 140 mmReference
Power (net)58.9 kWReference
Power (gross)62.6 kWReference
Air cleanerdryReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
PTO & Hydraulics
Rear PTOindependentReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
