Tractor · 1991Unverified
CaseIH 595
CaseIH 595 — 95 Utility Series · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
5640 to 7485 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Built in Doncaster, EnglandReference
Original price was $22,000 in 1994Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Case IH 3.4L 4-cyl dieselReference
Engine (gross)44.7 kWReference
Engine (net)41.8 kWReference
Case IHReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke98 x 111 mmReference
Power (net)41.8 kWReference
Power (gross)44.7 kWReference
Rated RPM2300Reference
Idle RPM700-2590Reference
Starter volts12Reference
Oil capacity9.8 LReference
Coolant capacity13.7 LReference
Transmission
8-speed partially synchronizedReference
16-speed partial power shiftReference
8-speed synchronized shuttleReference
16-speed creeperReference
Typepartially synchronizedReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
Oil capacity34.1 LReference
Four gears with high, low, and reverse ranges. Synchronized shifts within high and low ranges.Reference
Typepartial power shiftReference
Gears16 forward and 8 reverseReference
Four gears with high, low, and reverse ranges. Power shift between direct and lower speed in each gear.Reference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Four gears each in high and low ranges, both forward and reverse.Reference
TypecreeperReference
Four gears with high, low, and reverse ranges plus direct or creeper mode.Reference
PTO & Hydraulics
PTO (claimed)38.8 kWReference
Hydraulic system34.1 LReference
Typeopen centerReference
Capacity34.1 LReference
Valves1Reference
Pump flow57.2 lpmReference
Rear TypeIIReference
Rear lift1601 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Capacities
ROPS Fuel75.7 LReference
Cab Fuel111.7 LReference
Dimensions
Wheelbase214 cmReference
Weight5640 to 7485 poundsReference
Front tire7.50-16Reference
Rear tire14.9-24Reference
Ag front7.50-16Reference
Ag rear14.9-24Reference
Length360 cmReference
Width190 cmReference
Height (ROPS)245 cmReference
Height (cab)255 cmReference
2WD Clearance (front axle)56 cmReference
4WD Clearance (front axle)36 cmReference
2WD ROPS Shipping2558 kgReference
2WD Cab Shipping2921 kgReference
4WD ROPS Shipping3032 kgReference
4WD Cab Shipping3395 kgReference
CaseIH 595 attachments
front-end loaderReference
595 Serial Numbers
Location:Serial number plate on the tractor's right-front axle support.Reference
1991JJE0001501Reference
1992JJE0018291Reference
1993JJE0025736Reference
1994JJE0033230Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Case IH 2200 loaderReference
Case IH 2250 loaderReference
Case IH 2255 loaderReference
Speeds
With 16.9x30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
