Tractor · 1985Unverified
CaseIH 785
CaseIH 785 — 85 Utility Series · 69 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
69 hp
Weight
6376 to 7480 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Built in Doncaster, EnglandReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS. Cab available in the 795 XL version.Reference
Engine
CaseIH 4.0L 4-cyl dieselReference
Fuel tank112.0 LReference
Engine57.4 kWReference
CaseIH D-246Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke100 x 128 mmReference
Power57.4 kWReference
Fuel systemdirect injectionReference
Rated RPM2300Reference
Torque256.0 NmReference
Torque RPM1600Reference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)51.5 kWReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase224 cmReference
4WD Wheelbase216 cmReference
Weight6376 to 7480 poundsReference
Front tire7.50x18Reference
Rear tire16.9x34 (2WD)Reference
Standard tires (ag)Front: 7.50x18. Rear: 16.9x34 (2WD)Reference
Standard tires (ag)Front: 12.4x24. Rear: 16.9x34 (4WD)Reference
Length374 cmReference
Height (cab)264 cmReference
2WD Weight2892 kgReference
4WD Weight3392 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
