Tractor · 1985Unverified

CaseIH 856 XL

Name: CaseIH 856 XL
Brand: CaseIH

CaseIH 856 XL — Utility tractor · 85 hp. Reference specifications; pending source verification.

The CaseIH 856 XL is a tractor model with a rated power of 85 hp, falling within the mid-range of its class. It was manufactured from 1985 to 1987. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a 16-speed gearbox. Its operating weight ranges from 8465 to 9082 pounds and is suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

85 hp

Weight

8465 to 9082 pounds

Catalogue coverage

Variants represented

Richest spec table

62 rows

Recorded power

85 hp

Recorded weight

3839 kg

Transmissions

16-speed

Production years

1985-1987

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Utility tractorReference

Built in Neuss, GermanyReference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Cab standard with heat.Reference

Engine

International Harvester 3.9L 4-cyl dieselReference

Engine63.4 kWReference

International Harvester DT-239Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke98 x 129 mmReference

Power63.4 kWReference

Fuel systemdirect injectionReference

Rated RPM2300Reference

Torque310.0 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity12.0 LReference

Coolant capacity21.0 LReference

Transmission

16-speedReference

8-speedReference

TransmissionIH-Total-synchronReference

Gears16 forward and 8 reverseReference

Oil capacity42.0 LReference

Gears8 forward and 4 reverseReference

Capacities

Fuel106.0 LReference

Front axle9.0 LReference

PTO & Hydraulics

Pressure170.0 barReference

Valvesup to 3Reference

Pump flow25.0 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift3949 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

2WD Wheelbase238 cmReference

4WD Wheelbase234 cmReference

Weight8465 to 9082 poundsReference

Front tire10.00x16Reference

Rear tire16.9R34Reference

Standard tires (ag)Front: 10.00x16. Rear: 16.9R34Reference

2WD Length368 cmReference

4WD Length382 cmReference

2WD Height (cab)266 cmReference

4WD Height (cab)268 cmReference

2WD Weight3839 kgReference

4WD Weight4119 kgReference

2WD Clearance (front axle)52 cmReference

4WD Clearance (front axle)40 cmReference

2WD Front tread134 to 182 cmReference

4WD Front tread165 to 180 cmReference

Rear tread157 to 198 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps33Reference

Battery volts12Reference

Speeds

With 16.9R34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
