The CaseIH 885XL is a tractor with an 83 hp rated power output, a typical power rating for its class. It was manufactured between 1985 and 1990. The tractor is equipped with a 4-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission, and it has an operating weight of 3560 kg. It is suitable for use in operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
83 hp
Weight
3560 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
83 hp
Recorded weight
3560 kg
Transmissions
16-speed
Production years
1985-1990
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Built in Doncaster, EnglandReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Secura cab standard.Reference
Engine
CaseIH 4.4L 4-cyl dieselReference
Fuel tank112.0 LReference
Engine61.9 kWReference
CaseIH D-268Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke100 x 140 mmReference
Power61.9 kWReference
Rated RPM2400Reference
Torque296.0 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
TransmissionTorque AmplifierReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Pump flow46.9 lpmReference
Rear lift2381 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase216 cmReference
Weight3560 kgReference
Front tire12.4-24Reference
Rear tire16.9-34Reference
Standard tires (ag)Front: 12.4-24. Rear: 16.9-34Reference
Length374 cmReference
Height (cab)264 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
