Tractor · 1990Unverified

CaseIH 9210

CaseIH 9210 — Four-wheel Drive (4WD) tractor · 168 hp. Reference specifications; pending source verification.

The CaseIH 9210 is a tractor with a rated power output of 168 hp, placing it at the higher end of its class. It was manufactured between 1990 and 1995. The tractor features a 6-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. Its operating weight is 7711 kg, making it suitable for operations on land covering 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
168 hp
Weight
7711 kg

Catalogue coverage

Variants represented
2
Richest spec table
63 rows
Recorded power
168 hp
Recorded weight
7711 kg
Transmissions
12-speed full power shift
Production years
1990-1995
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference
Four-wheel Drive (4WD) tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $92,000 in 1995Reference
Four-wheel driveReference
Steeringhydrostatic power with articulation and front-axle steeringReference
Cab standard with air-conditioning. Optional deluxe cab adds side and rear window wipers plus internal storage compartments.Reference

Engine

CDC 8.3L 6-cyl dieselReference
Engine149.1 kWReference
CDCReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Power149.1 kWReference
Air cleanerdual paper elementsReference
Compression16.5:1Reference
Rated RPM2100Reference
Torque847.5 NmReference
Torque RPM1500Reference
Starter volts12Reference
Oil capacity20.8 LReference
Coolant capacity33.3 LReference

Transmission

12-speed full power shiftReference
Typefull power shiftReference
Gears12 forward and 3 reverseReference
Full power shift transmission operated with two right-hand levers; one for shifting gears and the other for forward/reverse. Skip-Shift feature allows the transmission to quickly shift from first into higher gears (4th, 6th, 8th).Reference

PTO & Hydraulics

PTO (claimed)125.3 kWReference
Hydraulic system68.1 LReference
Typeclosed centerReference
Capacity68.1 LReference
Pressure172.4 barReference
Valves4Reference
Total flow106.0 lpmReference
Rear TypeIIIReference
Controldraft control optionalReference
Rear lift5783 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference

Capacities

Fuel435.3 LReference

Dimensions

Wheelbase305 cmReference
Weight7711 kgReference
Front tire18.4-38Reference
Rear tire18.4-38Reference
Ag front18.4-38Reference
Ag rear18.4-38Reference
Length613 cmReference
Width303 cmReference
Height (exhaust)329 cmReference
Front tread152 to 330 cmReference
Rear tread152 to 330 cmReference

9210 Serial Numbers

Location:Under the left-side steps on front fenderReference
1990JCB0004600Reference
1991JCB0026501Reference
1992JCB0028400Reference
1993JCB0030500Reference
1994JEE0031773Reference
1995JEE0032808Reference
FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference
Battery volts12Reference

Speeds

With 18.4x38 tires.Reference
