The CaseIH C42 is a compact tractor model rated at 42 hp, manufactured between 1992 and 1996. It is powered by a 3-cylinder diesel engine, transmitting power through a mechanical front-wheel drive system with a hydrostatic transmission. The listed weight of the CaseIH C42 is 2360 kg, and it is suitable for tasks covering around 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
2360 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
42 hp
Recorded weight
2360 kg
Transmissions
16-speed
Production years
1992-1996
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorCaseIHReference
ManufacturerSteyrReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
Steyr 2.4L 3-cyl dieselReference
Fuel tank53.0 LReference
Engine31.3 kWReference
Steyr WD308Reference
dieselReference
3-cylinderReference
Displacement2.4 LReference
Bore/Stroke100 x 100 mmReference
Power31.3 kWReference
Rated RPM2400Reference
Torque150.5 NmReference
Torque RPM1350Reference
Transmission
16-speedReference
TransmissionsynchroReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Total flow29.1 lpmReference
Rear lift2000 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase198 cmReference
Weight2360 kgReference
Front tire7.50-16Reference
Rear tire12.4-32Reference
Ag front7.50-16Reference
Ag rear12.4-32Reference
Ag front8.3-24Reference
Length353 cmReference
Height229 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
