The CaseIH CS 48 is a compact tractor with a rated power output of 48 hp, making it suitable for smaller-scale applications. Manufactured from 1996 to 2001, this model features a 3-cylinder diesel engine and four-wheel drive with a hydrostatic transmission. Its listed weight is 2710 kg, and it is capable of handling areas of up to 200 acres. Specifications for this model are detailed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
2710 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
48 hp
Recorded weight
2710 kg
Transmissions
16-speed
Production years
1996-2001
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
Perkins 2.7L 3-cyl dieselReference
Fuel tank73.1 LReference
Engine35.8 kWReference
Perkins 903.27Reference
dieselReference
3-cylinderReference
Displacement2.7 LReference
Bore/Stroke95 x 127 mmReference
Power35.8 kWReference
Rated RPM2250Reference
Torque189.8 NmReference
Torque RPM1300Reference
Transmission
16-speedReference
TransmissionsynchroReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Total flow37.9 lpmReference
Rear lift2290 kgReference
Rear PTO Type430/540/ 750/1000Reference
Dimensions
Wheelbase212 cmReference
Weight2710 kgReference
Front tire7.50-16Reference
Rear tire14.9R28Reference
Ag front7.50-16Reference
Ag rear14.9R28Reference
Ag front10.5R20Reference
Length352 cmReference
Height233 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
