Tractor · 2001Unverified

CaseIH CS 52

Name: CaseIH CS 52
Brand: CaseIH

CaseIH CS 52 — CS Series · 45 hp. Reference specifications; pending source verification.

The CaseIH CS 52 is a compact tractor rated at 45 hp, featuring a 3-cylinder diesel engine. It was manufactured from 2001 to 2004 and is equipped with a four-wheel drive system and a 16-speed gearbox. The listed weight range is 5027 to 5952 pounds. It is suitable for applications covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Weight

5027 to 5952 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

45 hp

Transmissions

16-speed synchronized

Production years

2001-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Utility tractorReference

Two- or four-wheel driveReference

Power steeringReference

Disc brakesReference

Cab standard.Reference

Variants

CS522WDReference

CS52a4WDReference

Engine

Perkins 2.7L 3-cyl dieselReference

Fuel tank73.1 LReference

Engine38.8 kWReference

Perkins 903.27TReference

dieselReference

3-cylinderReference

Displacement2.7 LReference

Bore/Stroke95 x 127 mmReference

Power38.8 kWReference

Rated RPM2250Reference

Torque192.6 NmReference

Torque RPM1400Reference

Starter volts12Reference

Transmission

16-speed synchronizedReference

TypesynchronizedReference

Gears16 forward and 8 reverseReference

Clutchdry discReference

Four gears (1-4) in two ranges, plus reverse, with additional high/low range.Reference

PTO & Hydraulics

PTO (claimed)33.9 kWReference

Total flow34.1 lpmReference

Rear TypeIIReference

Rear lift2500 kgReference

Rear PTOindependentReference

Rear PTO Type430/540/1000Reference

Engine RPM430@2130Reference

Engine RPM540@2045Reference

Engine RPM540E@1506Reference

Engine RPM1000@2130Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

2WD Wheelbase216 cmReference

4WD Wheelbase212 cmReference

Weight5027 to 5952 poundsReference

Front tire7.50-18Reference

2WD Rear tire14.9R28Reference

2WD Standard tires (ag)Front: 7.50-18. Rear: 14.9R28Reference

4WD Standard tires (ag)Front: 10.5-20. Rear: 14.9-28Reference

2WD Length353 cmReference

4WD Length357 cmReference

Width189 cmReference

Height (cab)235 cmReference

2WD Ground clearance40 cmReference

2WD Ground clearance36 cmReference

2WD Front tread132 cmReference

4WD Front tread148 cmReference

Rear tread149 cmReference

2WD2280 kgReference

4WD2699 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Capacities

2WD Max capacity3999 kgReference

4WD Max capacity4199 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
