Tractor · 2001Unverified
CaseIH D25
CaseIH D25 — DX Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2334 to 2474 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS. Folding ROPS optional.Reference
Variants
D25gearReference
DX25hydrostaticReference
TC25similar New Holland modelReference
Engine
Shibaura 1.3L 3-cyl dieselReference
Fuel tank27.6 LReference
Engine (gross)18.6 kWReference
ShibauraReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke84 x 80 mmReference
Power (gross)18.6 kWReference
Air cleanerdual dry elementReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed gearReference
TypegearReference
Gears9 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)16.2 kWReference
Typeopen centerReference
Pump flow23.1 lpmReference
Total flow36.3 lpmReference
Steering flow13.2 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)741 kgReference
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Mid PTOtransmissionReference
Mid PTO Type2000Reference
Dimensions
Wheelbase160 cmReference
Weight2334 to 2474 poundsReference
Front tire5.50x16Reference
Rear tire11.2x24Reference
Ag front5.50x16 (2WD)Reference
Ag front7.00x14 (4WD)Reference
Ag rear11.2x24Reference
Lawn/turf front23x8.50-12 (2WD)Reference
Lawn/turf front24x8.50-14 (4WD)Reference
Lawn/turf rear13.6x16Reference
Industrial front25x8.50-14 (4WD)Reference
Industrial rear17.5Lx24Reference
Length270 cmReference
Width137 cmReference
Height (ROPS)222 cmReference
2WD Shipping weight1058 kgReference
4WD Shipping weight1122 kgReference
Ground clearance35 cmReference
Front tread110 cmReference
Rear tread108 cmReference
CaseIH D25 attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA420Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
CaseIH 757C Backhoe
Backhoe typeCaseIH 757C BackhoeReference
Transport height190 cmReference
2-Foot flat digging depth228 cmReference
8-Foot flat digging depth190 cmReference
Reach from pivot302 cmReference
Loading height167 cmReference
Bucket Rotation170°Reference
Swing Arc180°Reference
Bucket force1213 kgReference
Dipperstick force954 kgReference
CaseIH 758C Backhoe
Backhoe typeCaseIH 758C BackhoeReference
Transport height205 cmReference
2-Foot flat digging depth259 cmReference
8-Foot flat digging depth210 cmReference
Reach from pivot335 cmReference
Loading height195 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1610 kgReference
Dipperstick force1009 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
