Tractor · 2001Unverified

CaseIH D29

Name: CaseIH D29
Brand: CaseIH

CaseIH D29 — DX Series · 29 hp. Reference specifications; pending source verification.

The CaseIH D29 is a compact tractor with a rated output of 29 hp, classifying it among smaller options in its category. Produced from 2001 to 2003, this model features a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive via a hydrostatic transmission. The listed weight of the CaseIH D29 ranges from 2334 to 2474 pounds. It is suitable for tasks covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

29 hp

Weight

2334 to 2474 pounds

Catalogue coverage

Variants represented

Richest spec table

95 rows

Recorded power

29 hp

Recorded weight

1058 kg

Transmissions

9-speed gear

Production years

2001-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post fixed ROPS. Folding ROPS optional.Reference

Variants

D29gearReference

DX29hydrostaticReference

TC29similar New Holland modelReference

Engine

Shibaura 1.3L 3-cyl dieselReference

Fuel tank27.6 LReference

Engine (gross)21.6 kWReference

ShibauraReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke84 x 80 mmReference

Power (gross)21.6 kWReference

Air cleanerdual dry elementReference

Pre-heatingglow plugsReference

Rated RPM2800Reference

StarterelectricReference

Starter volts12Reference

Transmission

9-speed gearReference

TypegearReference

Gears9 forward and 3 reverseReference

PTO & Hydraulics

PTO (claimed)18.7 kWReference

Typeopen centerReference

Pump flow25.0 lpmReference

Total flow38.2 lpmReference

Steering flow13.2 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)741 kgReference

Rear PTOtransmissionReference

Rear PTO Type540 (1.375)Reference

Mid PTOtransmissionReference

Mid PTO Type2000Reference

Dimensions

Wheelbase160 cmReference

Weight2334 to 2474 poundsReference

Front tire5.50x16Reference

Rear tire11.2x24Reference

Ag front5.50x16 (2WD)Reference

Ag front7.00x14 (4WD)Reference

Ag rear11.2x24Reference

Lawn/turf front23x8.50-12 (2WD)Reference

Lawn/turf front24x8.50-14 (4WD)Reference

Lawn/turf rear13.6x16Reference

Industrial front25x8.50-14 (4WD)Reference

Industrial rear17.5Lx24Reference

Length270 cmReference

Width137 cmReference

Height (ROPS)222 cmReference

2WD Shipping weight1058 kgReference

4WD Shipping weight1122 kgReference

Ground clearance35 cmReference

Front tread110 cmReference

Rear tread108 cmReference

CaseIH D29 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery CCA420Reference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

CaseIH 757C Backhoe

Backhoe typeCaseIH 757C BackhoeReference

Transport height190 cmReference

2-Foot flat digging depth228 cmReference

8-Foot flat digging depth190 cmReference

Reach from pivot302 cmReference

Loading height167 cmReference

Bucket Rotation170°Reference

Swing Arc180°Reference

Bucket force1213 kgReference

Dipperstick force954 kgReference

CaseIH 758C Backhoe

Backhoe typeCaseIH 758C BackhoeReference

Transport height205 cmReference

2-Foot flat digging depth259 cmReference

8-Foot flat digging depth210 cmReference

Reach from pivot335 cmReference

Loading height195 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1610 kgReference

Dipperstick force1009 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
