Tractor · 2005Unverified

CaseIH DX23

Name: CaseIH DX23
Brand: CaseIH

CaseIH DX23 — DX Series · 23 hp. Reference specifications; pending source verification.

The CaseIH DX23 is a compact tractor with a rated output of 23 hp, produced from 2005 to 2008. It features a 3-cylinder diesel liquid-cooled engine, powering four-wheel drive via a hydrostatic transmission. The listed weight of the tractor is between 1495 and 1592 pounds. It is designed for use on small to medium-sized farms, covering areas up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Weight

1495 to 1592 pounds

Catalogue coverage

Variants represented

Richest spec table

89 rows

Recorded power

23 hp

Recorded weight

678 kg

Transmissions

hydrostatic

Production years

2005-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Variants

TC23DAsimilar New Holland modelReference

Engine

Shibaura 1.0L 3-cyl dieselReference

Engine (gross)17.2 kWReference

Shibaura S773Reference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.0 LReference

Bore/Stroke77 x 72 mmReference

Power (gross)17.2 kWReference

Compression24:1Reference

Rated RPM2850Reference

Idle RPM1100-3075Reference

Firing order1-2-3Reference

Starter volts12Reference

Coolant capacity3.5 LReference

Intake valve clearance0.203 mmReference

Exhaust valve clearance0.203 mmReference

Oil capacity2.8 LReference

Oil change100 hReference

Transmission

hydrostaticReference

9-speed gearReference

Gear Weight678 kgReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

TypegearReference

Gears9 forward and 3 reverseReference

Clutch184mm dry discReference

Three gears (1-3), plus reverse, (R), in three ranges. Tractor must be stopped, and clutch used, to shift gears or range.Reference

PTO & Hydraulics

Hydro PTO (claimed)13.0 kWReference

Gear PTO (claimed)13.8 kWReference

Hydraulic system16.0 LReference

Typeopen centerReference

Capacity16.0 LReference

Pressure127.5 barReference

Pump flow20.1 lpmReference

Total flow31.4 lpmReference

Steering flow11.4 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)573 kgReference

Gear Rear PTOtransmissionReference

Hydro Rear PTOindependentReference

Clutchmechanical dry discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2388 (gear)Reference

Engine RPM540@2503 (hydro)Reference

Gear Mid PTOtransmissionReference

Hydro Mid PTOindependentReference

Mid PTO Type2000 (1.0)Reference

Capacities

Fuel20.1 LReference

Dimensions

Wheelbase146 cmReference

Weight1495 to 1592 poundsReference

Front tire5-12Reference

Rear tire9.5-16Reference

Ag front5-12Reference

Ag rear9.5-16Reference

Ag front6-12Reference

Lawn/turf front23x8.50-12Reference

Lawn/turf rear31x13.5-15Reference

Industrial front23x8.50-12Reference

Industrial rear12-16.5Reference

Length270 cmReference

Width113 cmReference

Height (steering wheel)129 cmReference

Height (ROPS)206 cmReference

Height (Folded ROPS)173 cmReference

Hydro Weight722 kgReference

Ground clearance27 cmReference

Front tread84 cmReference

Rear tread89 cmReference

CaseIH DX23 attachments

front-end loaderReference

DX23 Serial Numbers

Location:Serial number decal on the front-right of the tractor frame.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery CCA450Reference

Battery volts12Reference

Attachment overview

CaseIH LX112 loaderReference

CaseIH LX330 loaderReference

Speeds

With 29x10.00-15 R3 rear tires.Reference

With 9.5-16 R1 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
